TRK 502/ 502X
40
The catalytic converter contains precious metals as the catalyst, which will transform the hazardous substances in
the exhaust gas, including carbon monoxide, hydrocarbon and nitrogen oxide into non-toxic carbon dioxide, water
and nitrogen through chemical reaction.
Since the catalytic converter is very important, the defective catalytic converter will pollute the air and damage
the performance of the engine, if the replacement is needed, please use the genuine parts or entrust the
distributors to replace.
BATTERY
Battery is under the seat cushion. The battery for the motorcycle is maintenance
free type. For the new motorcycle, please ask the dealer of the company to ll
electrolyte into the battery for you. It is not necessary to rell electrolyte in the future.
If you have to take out the battery for inspection, please follow these steps：
a. Shut o power switch of the motorcycle;
b. Remove the seat cushion;
Caution:
The catalytic converter is at high temperature area, please do not touch.
INSPECTION BEFORE DRIVING
12V8Ah（YTX9-BS）
MF (Maintenance Free) Battery

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
