STORAGE GUIDELINE
TRK 502/ 502X
52
Tire Tread
Driving a motorcycle with wheels excessively worn will reduce driving stability or even get out of control. When
the tire tread of front wheel is less than 1.6mm, and the rear wheel's tread is less than 2mm or even less,
replacement is strongly recommended.
STORAGE GUIDELINE
Storage
If you need to keep your motorcycle for a long time without using, it's suggested to following these instructions:
1. Change engine oil.
2. Lubricate drive chain
3. Detach the spark plug and add one teaspoon of (15~20cm3) clean engine oil to cylinder. Pushing the
starting switch for several times to distribute oil in the cylinder, and install the spark plug again.
4. Remove the battery. Keep the battery in proper place which can avoid freezing and the direct sunlight.
5. Clean and dry the motorcycle. Wax the surface of the paint.
6. Inate tire to the required pressure. Put the motorcycle on a block to make two tires o the ground.
7. Cover the motorcycle (no plastic or coating material) and keep it in the place with consistent temperature
and low humidity. Do not keep your motorcycle under direct sunlight.

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
