Benelli TRK 502 User Manual

TRK 502/ 502X
32
DRIVING TIPS
HOW TO START THE ENGINE
Insert the ignition key into the ignition lock and to " ". Step on the shift pedal to the neutral. The neutral
indicator light lightens up if the gear box is in neutral position. Start the engine by pushing the start switch.
Warning:
Do not start the engine indoor with bad ventilation or without ventilation. Do not leave a starting
motorcycle when no one else is around.
Caution:
Do not run the engine in high speed when you do not drive the motorcycle, or it will become overheating
and damage its inner parts.
INSPECTION BEFORE DRIVING

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
