Benelli TRK 502 User Manual

TRK 502/ 502X
39
3. Install the oil lter with the special tool and oil drain bolt.
4. Fill the engine with qualied engine oil
5. Make the engine runs in idling for several minutes and turn o.
6. Make sure the oil reaches the upper limit mark without any oil leakage.
SPARK PLUG
Clear away carbon deposit on the spark plug with small metal wire brush or spark plug cleaner during inspection
period noted in the maintenance schedule. Readjust the electrode gap of spark plug with feeler gauge and keep the
gap between 0.7～0.8mm.
Replace the sparking plug for each 6000km.
Type of Spark Plug: NGK CR8E
CATALYTIC CONVERTER
In order to meet the requirements of environmental emission, the muer of the motorcycle is
equipped with catalytic converter.
INSPECTION& MAINTENANCE
Do not Screw the spark plug too tight to avoid damaging the threads of cylinder cover.
Don't let the foreign objects fall into the engine through spark plug hole during
dismounting.
GAP

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
