Benelli TRK 502 User Manual

TRK 502/ 502X
45
Adjust the chain in following methods:
1. Support the motorcycle with side stand.
2. Loosen rear axle nut.
3. Loosen locknut.
4. Turn adjusting nut to adjust the tightness of the chain. Reference marks are adopted on left and right swing
arm and should reach the same grid after adjustment. Retighten the rear axle nut after adjust the chain
tightness to 28~35mm and conrm again.
During regular maintenance, check the following conditions of the chain:
(1) Loose pin (2) Damaged roller
(3) Rusty chain link (4) Twisted or snarled link
(5) Excessive free play (6) Loose chain
The sprocket is probably damaged, if any above-mentioned problems on the chain are found.
Check the following items for sprocket:
INSPECTION& MAINTENANCE
Notice:
When use new chain, check both front and rear sprockets if they are still in service limit and replace them,
if necessary

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
