Benelli ZAFFERAN 250 - THROTTLE CABLE ADJUSTMENT; Check; Adjust

22
play
①
THROTTLE CABLE ADJUSTMENT
NOTE:
Prior to adjusting the throttle cable free play, the
engine idling speed should be adjusted.
1.
•
Check:
Throttle cable free play
1
Out of specification → Adjust.
Free (throttle cable):
3 to
2.
•
Adjust:
5 mm at throttle grip flange
Throttle cable free play
*************************************
Adjustment steps:
NOTE:
Never accelerate the throttle when stopping the
engine.
•
•
Loosen the locknut
1
on the throttle cable.
Turn the adjuster
2
in or out until specified
free play is obtained.
Turning in → Free play is increased.
②
Turning out → Free play is decreased.
•
Tighten the locknut.
After adjusting, turn the handlebar to the
right and to the left to ensure that this does
not cause the engine idling speed to
change.
