EXHAUST SYSTEM INSPECTION
1.
•
Remove:
Side panels
2.
•
Inspect:
Nut
1
(exhaust pipe)
•
Loose / Damage → Tighten / replace.
Gasket (exhaust pipe)
Exhaust gas leaks → Tighten / replace.
3.
•
Inspect:
•
Bolt
2
(muffler)
Connecting bolt
3
(muffler)
Loose/Damage → Tighten/replace.
AIR FILTER CLEANING
1.
•
Remove:
•
Side panels
•
fixing screws of air filter
Air filter case cover
2.
•
Remove:
Air filter element
1
CAUTION:
Never operate the engine without the air fil-
ter element installed. Unfiltered air will
cause rapid wear of engine parts and may
damage the engine. Operating the engine
without the filter element will also affect the
EFI tuning, leading to poor engine
performance and possible overheating.
3.
•
Inspect:
Air filter element
Damaged → Replace.
4.
•
Clean:
Air filter element
1
Use foam filter cleaner to clean the element
NOTE:
After cleaning, remove the remaining cleaner by
squeezing the element.
