5. Brake
Maintenance instruction --------------------- 5.1
Failure diagnosis ------------------------------ 5.2
Front disc brake ------------------------------ 5.3
Rear disc brake -------------------------------- 5.4
5.1 Maintenance instruction
Note of Work
* Note
• Do not stain the brake assembly with oil spots during installation or disassembly.
• Clean it with required cleaning agent to maintain the brake performance.
* Check brake before riding.*
5.1.1 Specification
Item
Standard (mm)
Limit for use (mm)
Thickness of front brake disc
4.0
3.0
Thickness of front brake pad
6.0
3.0
Thickness of rear brake disc
4.0
3.0
Thickness of rear brake pad
6.0
3.0
EFI Motorcycle ZAFFERANO Diameter of front disc brake: φ250mm Diameter of rear disc
brake: φ250mm
5.1.2 Torque force
Fixing bolts for front/rear brake disc 22-29 N·m
Mounting bolts for front brake cylinder assembly 22-29 N·m
Mounting bolts for rear brake cylinder assembly 22-29 N·m
5.2 Failure diagnosis
Brake
Poor brake performance Slow reaction or tight lever
1. Improper adjustment of the brake 1. Improper adjustment of the brake
2. Abraded brake pad 2.Abraded brake pad
3. Improper installation of the brake pad 3. Improper installation of the brake pad
4. Stained brake pad or brake rotor
Abnormal noise
1. Abraded brake pad
2. Stained brake pad or brake disc
