Bennett 3000 Spec 300 Series Instruction Manual Preliminary Install Information
21
STEP 1: Determine the type of supply line needed from the model number’s seventh position on the serial label.
R = Remote Dispensers will require a submerged pump and pressurized supply line for each product.
S = Suction Pumps will require a suction supply line for each product.
STEP 2: Determine the number of product pipes required by finding the model number below.
Product Supply Lines Required
Use 1 product line plumbed to position 1
Use 1 product line plumbed to position 1
Use 1 product line plumbed to position 1 and 1 product line plumbed to position 2
Use 1 product line plumbed to position 1 and 1 product line plumbed to position 2
STANDARD MODELS
The following Inlets and Outlets sizes are used for Standard models. Refer the dispenser footprint for more information.
CAUTION: Dispensers must be installed
with provisions for expansion relief, which
will relieve at pressures not to exceed 50 psi
(345 mPA). Do not use line check valve
between dispenser and tank unless provided
with relief valve.
BIG FUELER MODELS
The following Inlets and Outlets sizes are used for Big Fueler models.
Pump Inside Dispenser Sump (Opening)
13“ x 30” (33 cm x 76 cm)
Satellite Inlets (Female)
Satellite Outlets (Female)
STEP 5 - FIND DISPENSER FOOTPRINT
Use the chart below to determine what footprint to use for your model number. Note: The letter X denotes options not identified.
3000 SERIES ELECTRONIC STANDARD
3700, 3800, 3900 Models | High Hose and Low Hose | Standard Flow Rates | Remote
3700, 3800, 3900 Models | High Hose and Low Hose | Standard Flow Rates | Suction
3XXXSNR-XXXX2
3XXXSNR-XXXXA
3700, 3800, 3900 Models | High Hose | Standard Flow Rates | Remote | Quad or Active 4
3700, 3800, 3900 Models | High Hose | Standard Flow Rates| Suction | Quad
3000 SERIES ELECTRONIC BIG FUELER
3700, 3800, 3900 Models | Low Hose | Remote | Master / Combo | High Flow Big Fueler
3700, 3800, 3900 Models | Low Hose | Remote | Satellite | High Flow Big Fueler
3700, 3800, 3900 Models | High Hose and Low Hose | Suction | High Flow Big Fueler
3700, 3800, 3900 Models | High Hose | Master | Remote | High Flow Big Fueler
3700, 3800, 3900 Models | High Hose | Satellite | Remote| High Flow Big Fueler
3700, 3800, 3900 Models | High Hose | Combo | Remote | High Flow Big Fueler
Pump Inside Dispenser Sump (Opening)
13“ x 30” (33 cm x 76 cm)
Satellite Outlets (Female)
