Bennett 3000 Series - Electronic Spare Parts; Hydraulic Spare Parts

Bennett 3000 Spec 300 Series Instruction Manual Service & Troubleshooting
69
ELECTRONIC SPARE PARTS
Notes:
 Many electronic circuit boards have a factory-rebuilt equivalent. All rebuilt boards have a part number prefix of “RB”. You must
use factory-rebuilt parts for all warranty service work. Please refer to the Distributor Policy Manual for program terms and
details.
 The dispenser quantity is recommended and may vary based on the options ordered for your dispenser.
Part No.
Description
Qty
RB105161
515 Pump Controller
1
130397
Circuit Board Assembly Lower 419 CPU with Temperature Control
1
130396
Circuit Board Assembly Lower 419 CPU without Temperature Control
1
130847
Circuit Board Assembly Upper CPU 719
1
RB121982
Circuit Board Assembly Upper CPU Current & Generic Loop Personality Module
1
RB121992
Circuit Board Assembly Upper CPU RS-485 Personality Module
1
131306
Commercial Display Board
1
122730s
Handle Switch Assembly
1
108014
Kit Pulser Replacement
1
131480
Pulse Output Board
1
131363
Retail (1 Tier) Display Board
1
131299
Retail (2 Tier) Display Board
1
133596
Satellite Controller Board
1
HYDRAULIC SPARE PARTS
Part No.
Description
Qty
107694s
Lip Seal SB-100 Meter for Service
1
130277
Check Valve Assembly Ball
2
114605
2-Stage Valve Assembly 1-1/2" 230VAC – FLANGED (Big Fueler)
1
114606
2-Stage Valve Assembly 1-1/2" 24VDC – FLANGED (Big Fueler)
1
114604
2-Stage Valve Assembly 1-1/2" 115VAC – FLANGED (Big Fueler)
1
N/A
Filter (Spin-On) – Standard
1
N/A
Kit Meter Piston Repair Standard
1
N/A
Kit SB-100 Diaphragm/Distributor
1
136921
Kit Valve Repair 1” Proportional
1
136922
Kit Valve Repair ¾” 2-Stage 115/230V
1
136923
Kit Valve Repair ¾” 2-Stage 24VDC
1
136924
Kit Valve Repair 1” 2-Stage
1
136925
Kit Valve Repair 1-1/2” 2-Stage
1
136926
Kit Valve Repair ¾” Proportional
1
Error Code
Error Text
Description
6-Digit Display
8-Digit Display
76
VSIDE2
VACSIDE2
Vapor Vacuum – Side 2 Error – Fast Flow or Over Current
77
VAPOR
VAPOR
TST Vapor Recover Error Signal Received
83
PLSRDC
PDISCONN
Pulser Disconnected
93
PLSRCC
PCIRCUIT
Pulser Circuitry Error
94
619DCN
619DISCN
Lower I/O is Not Responding
99
GENERL
GENERAL
CPU Failure – Addition Error
d5
DOORSS
DOORSENS
Door is open sensor (DS)
