TEBEVERT III INVERTER SYSTEM (120 VDC)
07.11.2011 13 028-0009-006
• Female connector for the protective earth of the SBS ( )
• Female connector for the mains input (L1)
• Female connector for the SBS output and the inverter output (N)
• Female connector for the SBS output (L)
• Female connector for the inverter input (1L)
• Male connector for the data bus (X20; X21)
• Data line to the inverter slots
• Male connector for the auxiliary DC supply and the voltage-free fault
messaging system (X22)
The SBS carrier is equipped with two guiding rails insuring the SBS module is
accurately positioned and a reliable contact is made.
