TEBEVERT III INVERTER SYSTEM (120 VDC)
07.11.2011 36 028-0009-006
4.3.6 AC CABLE REQUIREMENTS FOR 25kVA,
220VAC AC INPUT SYSTEM
Supply conductor
Maximum system
capacity
Suggested rating of
disconnect device
Mains 5 inverters 220VAC /150A
Terminal
designation
Connection
type
Terminal/connection
capacity
Suggested
protection
X2:L1/L2/PE 5 inverters
Compression Type
2 AWG - 4/0 150A
4.3.7 AC CABLE REQUIREMENTS FOR 25kVA,
240VAC AC INPUT SYSTEM
Supply conductor
Maximum system
capacity
Suggested rating of
disconnect device
Mains 5 inverters 120/240VAC /150A
Terminal
designation
Connection
type
Terminal/connection
capacity
Suggested
protection
X2:L1/L2/PE 5 inverters
Compression Type
2 AWG - 4/0 150A
4.3.8 AC CABLE REQUIREMENTS FOR 25kVA,
480VAC AC INPUT SYSTEM
Supply conductor
Maximum system
capacity
Suggested rating of
disconnect device
Mains 5 inverters 480VAC /70A
Terminal
designation
Connection
type
Terminal/connection
capacity
Suggested
protection
X2:L1/L2/PE 5 inverters
Compression Type
2 AWG - 4/0
70A
