TEBEVERT III INVERTER SYSTEM (120 VDC)
07.11.2011 38 028-0009-006
4.4 INSTALLATION OF THE UNITS
Prior to the installation of the Static By-Pass Switch (SBS) and the
inverters in the inverter system, the following points must be checked and
observed.
• Verify that the units are of the same type and model (120VDC /
120VAC) Since all inverters of this series are identical for the user, the
exact model of the unit must be checked.
• Verify the position of circuit breaker (F1) located on the rear of the
module. It must be in the “ON” position, position 1.
• Verify the SBS, as described in Chapter 4.2
• Verify all the inverters set to the same frequency (50Hz or 60Hz)
(See Chapter 4.1)
• Verify that (S1) on front of each module is switched off.
(Power switch position ON/OFF)
