TEBEVERT III INVERTER SYSTEM (120 VDC)
07.11.2011 17 028-0009-006
3.5.2 TERMINALS AND OPERATING ELEMENTS
All terminals and operating elements are installed on the front or rear of
the inverter module.
kg
Fig. 7: Front view of the inverter
1 weight notice of the individual plug-in unit
2 type designation
3 on/off switch (S1)
4 LED signalling panel
1
2 3
4
