TEBEVERT III INVERTER SYSTEM (120 VDC)
07.11.2011 35 028-0009-006
4.3.3 AC CABLE REQUIREMENTS FOR 25kVA,
120VAC AC INPUT RATINGS
Supply conductor
Maximum system
capacity
Suggested rating of
disconnect device
Mains 5 inverters 120VAC/250A
Terminal
designation
Connection
type
Terminal/connection
capacity
Suggested
protection
X2: L1/N/PE 5 inverters
Compression Type
2 AWG - 4/0
250A
4.3.4 AC CABLE REQUIREMENTS FOR 25kVA,
120/240VAC AC INPUT SYSTEM
Supply conductor
Maximum system
capacity
Suggested rating of
disconnect device
Mains 5 inverters 120/240VAC/150A
Terminal
designation
Connection
type
Terminal/connection
capacity
Suggested
protection
X2: L1/L2/PE 5 inverters
Compression Type
2 AWG - 4/0
150A
4.3.5 AC CABLE REQUIREMENTS FOR 25kVA,
208VAC AC INPUT SYSTEM
Supply conductor
Maximum system
capacity
Suggested rating of
disconnect device
Mains 5 inverters 120/208VAC/150A
Terminal
designation
Connection
type
Terminal/connection
capacity
Suggested
protection
X2:L1/L2/PE 5 inverters
Compression Type
2 AWG - 4/0
150A
