TEBEVERT III INVERTER SYSTEM (120 VDC)
07.11.2011 7 028-0009-006
The input of the terminals and distribution positions within the cabinet
depend on the supplied configuration. Refer to the equipment elevation
drawing for specific terminal sizes and placement.
The inverter’s static by-pass switch is only operational when properly
installed into its corresponding position.
3.1 PSJ TYPE EQUIPMENT CABINET
The Benning TEBEVERT III system is built and supplied into a 19” PSJ
type, fully enclosed, floor standing cabinet (23.6” X 23.6” X 7’0” outside
overall dimension). Cabinets are available for New Equipment building
Standards (NEBS) and non-NEBS applications. Deep cabinets (600mm x
800mm or 23.6” x 31.5” x 7’0”) are available for special applications i.e.
raised floor, etc. consult with Benning at time of order.
