No. Name Fuction
7 AV/SV AUDIO IN 1 L/
R
Connect to the left /right audio channel output (for
compositive video or S-video output) of video devices.
See "Connect to a composite video input" on page 18 and
"Connect to a S-Video input" on page 18.
8 AV 1
Connect to the Compositive video (AV) output of video
devices. See "Connect to a composite video input" on page
18.
9 AUDIO OUT L/R
Connect to the audio input of audio devices. See "Connect
to a Stereo audi
o Output" on page 21.
10 RF IN
Connect to the outdoor TV antenna or the CATV signal
cable. See "Connect the antenna cable" on page 4.
11 Media USB
Connect your USB drive to the USB port on the TV set.
You may select playing video/music/photo/text files. See
"Features for Multimedia Playback" on page 30 for detailed
description.
12 S-VIDEO IN
Connect to the S-Video output of video devices. See
"Connect to a S-Video input" on page 18.
13
AV 2
Connect to the Compositive video (AV) output of video
devices. See "Connect to a composite video input" on page
18.
14 AV/AUDIO IN 2 L/R
Connect to the audio output of the Left/Right Channel that
corresponds to the Composite Video output of the external
video device. See "Connect to a composite video input" on
page 18.
15 Headphone output
Connect to your headphones. By connecting the
headphones, you can listen to the sound from the TV
on
headphones.
*
If you connect the headphones, the TV speakers will be
turned off.
