Supported Component Video input signal modes
Resolution
H-frequency
(KHz)
V-frequency
(Hz)
Clock frequency
(MHz)
Note
720 x 480i 15.735 60 13.5
720 x 576i 15.625 50 13.5
720 x 480p 31.47 60 27
720 x 576p 31.25 50 27
1280 x 720p60 45 60 74.25
1280 x 720p50 37.5 50 74.25
1920 x 1080i60 33.75 60 74.25
1920 x 1080i50 28.13 50 74.25
1920 x 1080p60 67.5 60 148.5
1920 x 1080p50 56.25 50 148.5
The PC/DVI and Component Video resolutions not listed in these tables will not be •
recognized and displayed.
When you connect your TV to a PC, you should adjust the resolution of the output from •
the PC to 1920 x 1080@60Hz, will giving you the best image quality in this case.
If you find the TV image has been misplaced•
or
the image are flashing after changing the
resolution, you should activate the auto adjust function in the PC menu to fix the problem.
See "Auto Adjust" on page 27.
