Operating manual 21.12.98
ACP 3000 — 0.37–15.0 04_GB
66
NOTES:
Level 1 Parameters shown shaded.
(1) Additional parameters that are only available when using the PI controller and when
the
81-PRGNO parameter is set to a value between 80 and 95 (see page 56). See
chapter 6, from page 51 on, for further information about the PI controller.
(2) Extended parameters when using the PI controller. For further information about the
PI controller, see chapter 6, as from page 51.
5B-MSAT Motor Saturation Level 47% 15–80% 42
61-LTLF Load Torque Limit Forward 150% 10–150% 42
62-LTLR Load Torque Limit Reverse 150% 10–150% 42
63-RTLF Regenerative Torque Limit Forward 80% 10–110% 42
64-RTLR Regenerative Torque Limit Reverse 80% 10–110% 42
65-SLIP Slip Compensation 0.00%
(2)
0.00–12.00%
43/56
66-STAB Current Stability Adjustment 3 0–4 43
67-TOL Timed Overload Trip Point 0% 0–100% 43
68-NRST Trip Restart Number 0 0–8 44
69-DRST Restart Delay Time 0.00 s 0.00–60.00 s 44
6A-TOLC Timed Overload Characteristic 0 0–7 45
70-MCAL Analog Meter Output Calibration MET1 Set for10 VDC 0–255 45
71-METER Analog Meter Output Selector MET1 1
(2)
0–5
45/56
72-ST1 Open Collector Output 1 7 0–10 46
75-STR Auxiliary Relay Output 1 0–10 46
77-MOL Motor Overload Input 2 0–3 47
78-MCAL2 Analog Meter Output Calibration MET2 0–20 mA or 4–20 mA;
set for 20 mA
0–255 47
79-MET2 Analog Meter Output Selector MET2 3
(2)
0–15
47/56
81-PRGNO Special Program/PI Control Characteristics 0 0–9999 48/56
82-START Start Options 1 0–11 48
83-PWM PWM Carrier Frequency Selector 1 0–5 49
84-DISP Display Option Setting 0 0–3000 49
87-ACODE Security Access Code 0 0–999 50
97-RVLVL2 Software Revision Level 2 0.00–12.75 50 Read-only
A1-FCORR Frequency Correction
(1)
0.00–400.0 Hz
55
A6-ERROR2 Final Error
(1)
–
55 Read-only
A7-ERROR1 Initial Error
(1)
–
55 Read-only
A8-SIPART Integral Sum
(1)
–
55 Read-only
B3-KP Proportional Gain
(1)
0–255
55
B4-KI Integral Gain
(1)
0–255
55
B5-KIN VIN1 Scaling
(1)
0–255
55
PARA-
METER
DESCRIPTION FACTORY
SETTING
RANGE PAGE CUSTOMER
SETTING
