3.3 GENERAL TECHNICAL FEATURES
The table below contains the technical data of the M10.
Features M10
Structure
Integral Flow meter
DN Range
DN50/2” ÷ DN150/6”
Nominal Pressure
16 bar
Process Connection
Victaulic OGS
Fluid Conductivity
> 20 µS/cm
Process Temperature Range
0 ÷ 80 °C (32 ÷ 176 °F)
Materials in contact with
water
Flow tube: Glass fibre reinforced plastic
Electrodes: AISI316L
Power supply
Battery Powered: 3.6 V Lithium Battery
Mains Powered: 12Vdc (10.8 ÷ 13.2V), max 100mA
Consumption
0,25W÷1W (Mains powered)
Outputs
2 passive outputs (1 programmable), SSR Type (dry contact), galvanically insulated
Max. load +/- 35VDC, 100 mA protected against short circuits, minimum pulse
duration 5ms.
RS458 2 wire /half-duplex
Communication
Modbus RTU Slave
Bluetooth
Display
LCD Segment display, with dedicated status icons, 8+6 digits
User Interfaces
Magnetic reed
Bluetooth Mobile App
Euromag Link Software
Process memory
100,000 data lines
Programmable frequency 1 ÷ 120 minutes (15 minutes factory standard)
Metrological certificate
OIML R49-1:2013 / MID 2014/32/EU - Class 2 (if requested)
Temperature range
Ambient: -20 ÷ 60 °C (-4 ÷ +140 °F)
Process: 0 ÷ 80 °C (32 ÷ 176 °F)
Storage: -40 ÷ 70 °C (-40 ÷ +158 °F)
Technical units
m, m3, l, ML, ft3, gal
Totalizers
5 (2 Positive, 2 Negative, 1 Net)
Alarms and status icons
Status icons displayed and alarms recorded in the data logger
Self diagnostic
Excitation failure
Excessive ambient temperature
Wet electronic board
Low battery level / Mains voltage out of range
Pulses overlapping
Bluetooth communiccation error
Empty pipe
Measurement error
Software/memory malfunction
Mains power interruption
Software for communication
and programming
Bluetooth Mobile App - Mag-Net
Euromag Link Software (trough Bluetooth dongle, or RS485 interface)
Data Protection
Customizable password protection
EEPROM Memory with safe data storage management
