BERMAD M10 - Modbus Address

Instruction Manual
3131
Modbus Address Table
See document: “M10 MODBUS CMD04-03” for more detailed informations on Modbus protocol configuration.
The communication interface RS485 is used in combination with Euromag-Link software or with other
computer systems compatible with the MODBUS RTU standard; for further information, see the MODBUS
address manual.
MODBUS ADDRESS PARAMETER UNIT NUM. BYTES DATA TYPE
1662 Instantaneous flow rate in fixed unit m
3
/h 4 Float
1664 Instantaneous fluid velocity m/s 4 Float
1666 Instantaneous flow rate in technical unit Tech. Unit 4 Float
1668 Instantaneous flow rate in % of full scale % FS 4 Float
1672 Positive totalizer in fixed unit m3 4 Float
1674 Negative totalizer in fixed unit m³ 4 Float
1676 Partial positive totalizer in fixed unit m³ 4 Float
1678 Partial negative totalizer in fixed unit m³ 4 Float
1680 Positive totalizer in technical unit Tech. Unit 4 Float
1682 Negative totalizer in technical unit Tech. Unit 4 Float
1684 Partial positive totalizer in technical unit Tech. Unit 4 Float
1686 Partial negative totalizer in technical unit Tech. Unit 4 Float
