BERMAD M10 - Battery Installation

M10
Instruction Manual
34
4.7 BATTERY INSTALLATION
Follow the instructions below to install the battery:
T25
0- Initial configuration
1- Remove the 2 hex-lobular (T25) drive screws
2- Remove the battery compartment (If needed help
yourself with a flat screwdriver to remove the cap)
