Bernard Controls AQ Logic Series User Manual

English
43
5.10 Set Relays configuration
Available relays can be configured for specific functions.
How to set relays configuration

Following procedure runs through the procedure for the 3 standard
relays installed. Apply the same procedure for optional relays.
1. Enter the menu then go to Settings > Remote feedbacks.
The Remote Feedbacks screen appears.
2. To set a signaling relay, select it and validate with OK.
3. The Signaling Relay screen appears.
4. To set the condition, select Contact closed or Contact open
option then validate with OK
5. Validate Continue with OK. Signaling options screen
appears.
