Bernette B05 Crafter - Machine Overview - Top View

My bernette
10
2020-09 EN 5220105.00A.04
Accessory box
1
2
1 Compartment for needle set 2 Compartment for spool disc
Overview top
1
2
3
4
5
6
7
8
9
10
11
12
13
1 Needle position dial 8 Spool pin
2 Thread take-up lever 9 Opening, additional spool pin
3 Bobbin winder pre-tension 10 Bobbin winder unit
4 Presser foot pressure adjustment knob 11 Handwheel
5 Thread pretension 12 Bobbin winder unit stopper
6 Thread guide 13 Stitch width dial
7 Carrying handle
