Bernette B05 Crafter - Maintenance and Cleaning; Cleaning the Feed Dog

Maintencance and cleaning
67
2020-09 EN 5220105.00A.04
8 Maintencance and cleaning
8.1 Cleaning the feed dog
Remaining threads under the stitch plate must occasionally be removed.
CAUTION
Electronically driven components
Risk of injury near the needle and the hook.
> Raise the presser foot.
> Switch off the machine and disconnect it from the power supply.
> Switch off the machine and disconnect it from the power supply.
> Remove the presser foot and the needle.
> Lower the feed dog.
> Push the unlocking lever (1) to the right and remove the bobbin cover (2).
1
2
> Loosen both screws and remove the stitch plate.
> Clean the feed dog with the brush.
> Insert the stitch plate. Insert and tighten the two screws.
> Insert the bobbin cover.
> Lift the feed dog.
> Insert a needle.
