Sewing preparation
28
2020-09 EN 5220105.00A.04
> Guide the thread to the thread guide above the needle.
> Thread the thread into the left needle manually.
> Guide the thread from the external spool pin (orange) in the direction of the arrow to the left side of the
thread tension disc (1).
> Guide the thread to the thread guide above the needle.
> Thread the thread into the center needle manually.
> Guide the thread from the vertical spool pin (blue) in the direction of the arrow to the right side of the
thread tension disc (1).
> Guide the thread to the thread guide above the needle.
> Thread the thread into the right needle manually.
NOTICE
Needle breakage caused by incorrect presser foot, stitch or needle position
If the presser foot, stitch or needle position is incorrect, the needle can collide with the presser foot or stitch
plate and break.
> Fit the zigzag foot.
> Set a straight stitch.
> Set the needle to the center position.
Winding the bobbin thread
1 Spool disc 3 Bobbin winder pre-tension
2 Thread guide 4 Spool pin
> To prevent slippery threads from catching or breaking, pull the spool net over the spool.
> Place the thread spool and the appropriate spool disc on the spool holder. Use the small spool disc for
smaller spools.
