14
Sewing preparation
█
turn power switch to «I» (on)
█
place empty bobbin on spindle
Then proceed as mentioned above.
█
push engaging lever A against bobbin
►
the winder works automatically
►
the Display to wind the bobbin is opened
█
move the round knob in the Display to the left/right or
█
turn the stitch width knob (see page 10)
►
the winding speed is altered
►
the motor will stop automatically when the bobbin is full
►
the Display is closed
█
remove bobbin and
█
pull the thread over thread cutter A to cut it
Winding a bobbin
Bobbin winding while sewing
█
attach foam pad on the vertical spool pin B
█
place thread on the vertical spool pin
█
following the direction of the arrow, take the thread through the thread
guide C and
█
guide around the pre-tension stud
A
A
█
place foam pad on the spool pin
█
place thread on the spool pin
█
attach appropriate spool disc
█
following the direction of the arrow, take the thread through the rear guide
and round the pre-tension stud
█
wind the thread two to three times around the empty bobbin
█
cut off any excess thread on the thread cutter A
C
Appropriate spool disc
Diameter of thread spool determines disc size. There must be no
gap between the disc and the spool.
B
It is recommended to reduce the winding speed when winding from
the vertical spool pin.
