Bernina 500 - User Manual

Questions and Answers

S
Seth MorganAug 17, 2025
What to do if my Bernina Sewing Machine skips stitches?
- K
  Kimberly WalshAug 17, 2025
  Skipped stitches can occur due to several reasons: * The needle may be incorrect; use the needle system 130/705H. * The needle might be blunt or bent; replace the needle. * You may be using a poor-quality needle; use a new BERNINA quality needle. * The needle may be incorrectly inserted; insert the needle with the flat side to the back as far up as it will go into the needle holder and tighten the screw. * The needle point may be incorrect; match the needle point to the texture of the material.
M
Michael CollinsAug 19, 2025
What to do if the lower thread breaks on my Bernina Sewing Machine?
- S
  Sandra RobertsAug 20, 2025
  The lower thread may break if: * The bobbin case is damaged; replace the bobbin case. * The needle is blunt or bent; replace the needle.
M
mooredanielAug 22, 2025
What to do if there is an error during software update of my Bernina Sewing Machine?
- Y
  Yvonne McleanAug 22, 2025
  If you encounter an error during a software update: * If the USB stick is not recognized, use a BERNINA USB stick. * If the update process is blocked and the hourglass on the display is inactive, remove the USB stick. * If the date of the software update cannot be found, switch the machine off, then on. * Follow the instruction on the display. * Unzip the update data. * Save data of the software update directly on the data medium and not in a file on the USB stick.
S
Scott ThompsonAug 26, 2025
Why are my stitches uneven on my Bernina 500?
- R
  Randall DelgadoAug 26, 2025
  Uneven stitch formation can occur for several reasons: * The upper thread may be too tight or too loose; in this case, adjust the upper thread tension. * The needle might be blunt or bent; replace it with a new BERNINA quality needle. * You may be using a poor-quality needle or thread; use a new, quality BERNINA needle and quality thread, respectively. * The needle and thread combination may be incorrect; match the needle with the thread size. * The machine may be incorrectly threaded; rethread it. * An incorrect bobbin case may be in use; use the supplied bobbin case marked with the triangle.
K
Katelyn AlvaradoAug 28, 2025
Why does the upper thread on my Bernina 500 Sewing Machine keep breaking?
- K
  Kayla CrawfordAug 28, 2025
  The upper thread may break because: * The needle and thread combination are incorrect; match the needle with the thread size. * The upper thread is too tight; reduce the upper thread tension. * The machine is incorrectly threaded; rethread it. * You are using poor quality thread; use quality thread. * The thread is caught in the area of the thread take-up lever; remove the thread remnants.
C
Carol LeeAug 31, 2025
What causes uneven stitching on my Bernina Sewing Machine?
- J
  Jennifer BurgessAug 31, 2025
  Uneven stitching can be caused by: * Thread remnants between the thread tension discs; fold a piece of thin material and slide the folded edge (not the raw edges) between the thread tension discs. * The machine being incorrectly threaded; rethread it. * Thread remnants below the bobbin case spring; remove the thread remnants under the spring.
B
Brenda AndersonSep 2, 2025
What causes my Bernina Sewing Machine needle to break?
- C
  Chad HurstSep 3, 2025
  Needle breakage can occur because: * The needle is incorrectly inserted; insert the needle with the flat side to the back as far up as it will go into the needle holder and tighten the screw. * There is knotted thread; use quality thread.
J
jamiecaseySep 5, 2025
Why is my Bernina 500 running at a low speed?
- H
  Heather KimSep 5, 2025
  If your sewing machine's speed is too low, it could be due to: * An unfavorable room temperature; place the machine in a warm room one hour before use. * Settings in the Setup Program; adjust the sewing speed in the Setup Program.
K
Kevin AndersonSep 8, 2025
Why isn't the upper thread indicator reacting on my Bernina 500?
- L
  lhernandezSep 8, 2025
  The upper thread indicator might not react due to settings in the Setup Program; activate it in the Setup Program.
T
tracyfarleySep 12, 2025
Why isn't the bobbin thread indicator reacting on my Bernina Sewing Machine?
- K
  kerryadamsSep 12, 2025
  The bobbin thread indicator might not react due to settings in the Setup Program; activate it in the Setup Program.

Summary

Important Safety Instructions

General Safety Guidelines

Basic safety instructions covering electrical shock, fire hazards, and proper machine operation to prevent injury.

Operational Safety Precautions

Precautions for using accessories, maintaining ventilation, and avoiding contact with moving parts during operation.

My BERNINA

Machine Component and Module Overviews

Detailed diagrams and labels identifying various parts of the BERNINA 500 sewing machine.

Needle, Thread, Fabric, and Embroidery Fundamentals

Embroidery Preparation

Machine Setup, Connections, and Powering On

Thread Handling, Setup, and Bobbin Procedures

Module, Hoop, and Stabilizer Management

Hoop Attachment and Positioning

Setup Program

Embroidery Settings and Calibration

Adjusting embroidery settings like thread tension, speed, calibrating the hoop, and thread cutting options.

Personal and Machine Settings Management

System Settings

Creative Embroidering

Motif Editing and Manipulation Tools

Tools and techniques for editing, scaling, rotating, mirroring embroidery motifs, and bending text.

Advanced Embroidery Features and Motif Management

Advanced functions like checking motif position, endless embroidery, combining, and grouping motifs.

Color, Thread, and Motif Administration

Embroidery Process, Free Arm, and Motif Administration

Embroidery

Embroidery Process Control and Speed Adjustment

How to start, stop, manage speed, and adjust tension during the embroidery process.

Appendix

Maintenance, Cleaning, and Lubrication Procedures

Troubleshooting Common Faults and Error Messages

A guide to common faults, their causes, solutions, and interpreting error messages on the display.

Bernina 500 Specifications

General

Color Touch Screen	Yes
USB Port	Yes
Thread Cutter	Automatic
Free Arm	Yes
Display	Color Touch Screen
Maximum Sewing Speed	1000 stitches per minute
Needle Threader	Yes
Speed Control	Yes
Machine Type	Embroidery and Sewing Machine
