Bernina 500 - Calibrating the Hoop

Setup Program
51
> Touch the icon «Embroidery settings».
> Touch the icon «Center the embroidery motif».
> To open the embroidery motif at the saved position, set the switch «Restore saved embroidery motif
position»
to «I».
> To open the embroidery motif in the center of the hoop, set the switch «Restore saved embroidery motif
position»
to «0I».
Calibrating the hoop
The calibration of the embroidery hoop is the coordination of the needle to the center of the embroidery
hoop.
Prerequisite:
• The embroidery module is connected.
• The hoop is fitted with the corresponding embroidery pattern.
> Touch the icon «Home».
> Touch the icon «Setup Program».
> Touch the icon «Embroidery settings».
> Touch the icon «Calibrating the hoop».
> Use the arrow icons on the display to move the needle precisely to the center of the pattern.
1
> Accept the needle position using the icon «Confirm».
