My BERNINA
20
Illustration Name Purpose
Medium embroidery hoop To embroider medium-sized
embroidery motifs up to
100x130mm (3.94 × 5.12in).
Including the template for
precise fabric positioning.
USB Connecting cable To transfer data from the
computer to the machine or vice
versa.
Embroidery needle assortment For embroidering.
Template holder To place and remove the
template in or out of the
embroidery hoop.
Net for upper thread spool To support an even unwinding
of the thread with slippery
embroidery threads.
1.5 Overview User Interface
Overview functions/visual information
2
1
3
4
5
1 Upper thread tension 4 Stitch plate/Needle selection
2 Presser foot indicator / presser foot selection 5 Threading the bobbin thread
3 Embroidery hoop display/Embroidery hoop
selection
