Extension Table (L 450 optional)
The extension table provides a large working surface for your sewing projects.
⦁
To attach, slide the extension table from the left side horizontally along the ditch until
it engages.
⦁
To remove, slide the table to the left side while pushing the release button at the back
of the table.
1 Release button
Retractable Top Thread Guide
⦁
Pull up the retractable thread stand fully, turning it slightly until the two positioning pins
engage. This will align the Thread Guide (1) parallel to the Thread Stand.
⦁
Make sure the lower part of the telescopic support rod (2) is pulled out of the housing
all the way to achieve the optimum height.
⦁
When storing the overlock machine, the base of the retractable thread stand can be
pushed back into the housing.
⦁
For transportation the thread guides hold the thread spools in place by bringing down
the stand as illustrated.
1 Thread Guide
1
1
1
