Appendix
Technical Summary
L 450 L 460
Stitch Formations
⦁
16 stitches
⦁
1-2 needles
⦁
2 loopers
Needle system
⦁
130/705H (HAx1)
Cutting width
⦁
5-9 mm from the left needle
⦁
3-7 mm from the right needle
Stitch length
⦁
0.8 - 4.0 mm
Differential feed
⦁
stretching 0.7 - 1
⦁
gathering 1 - 2
Presser foot lift
⦁
6 mm (= max. fabric thickness)
⦁
9 mm with front foot lift (FFL)
Sewing light
⦁
2 x LED
Sewing speed
⦁
up to 1200 stitches/min.
⦁
1500 stitches/min.
Safety features
⦁
safety switch for looper cover, sewing
table and presser foot lift
⦁
Safety LED
Foot control
⦁
Type YC-483N for 230V
⦁
YC 482E for 120V (Canada/USA)
⦁
BERNINA LV 1
Dimensions witout Retractable Guide
(L x B x H) mm
⦁
320 x 305 x 295
⦁
320 x 305 x 295
Dimensions with extension table/cut-offs bin
(L x B x H) mm
⦁
548 x 398 x 295
Weight (kg)
⦁
8.2
⦁
9.8 kg (incl. extension table and knee
lever)
Boxed size mm
⦁
387 x 387 x 387
⦁
463 x 387 x 387
Boxed weight (kg)
⦁
11.0
⦁
13.7
