Bernina L460 - Threading the Lower Looper (Red)

26
L 450
L 460
Threading and Sewing
1
2
3
3
4
4
5
6
6
8
9
10
7
8
7
9
10
Threading the lower looper (red)
⦁
Prepare maschine for threading.
(„Threading - General information“ see
page 24).
⦁
Make sure that the handwheel is in
threading position (Handwheel position
indicator window) (1) and the presser
foot is lifted.
⦁
Insert the thread from the back through
the thread guide (2).
⦁
Thread through the pretension (3).
⦁
Pull the thread through the thread ten-
sion (4).
⦁
Insert the thread into the thread guides
(5) and (6).
⦁
Push down the lower looper threader
lever (7).
⦁
Thread through the thread guides on
the lower looper (8) and (9).
⦁
thread the lower looper eye (10).
⦁
Pull about 10 cm/ 4" of thread to the
back and place it under the presser
foot.
⦁
The Lower Looper Threader lever is
brought back up by turning the hand-
wheel.
1
1
2
3
3
5
4
4
6
6
9
9
7
7
8
8
10
10
7
