Knife
Deactivating the knife
⦁
Open the sewing table and the looper cover.
⦁
Press the knife activating knob on/off (1) und turn clockwise (2) until the knife engages
at the lower position.
⦁
Close the sewing table and the looper cover.
Activating the knife
⦁
Open the sewing table and the looper cover.
⦁
Press the knife activating knob on/off (1) und turn counter-clockwise (2) until the knife
engages at the upper position.
⦁
Close the sewing table and the looper cover.
1
2
3
Thread cutter
⦁
After sewing, bring the thread up and pull it over the cutter from back to front.
⦁
Pull the thread down to cut it.
⦁
The chain of thread will be clamped in the thread cutter to be ready for the next piece
of fabric.
Seam Guide right
⦁
Open the sewing table.
⦁
Attach the Seam Guide by adjusting the two hooks on the right
side to the Stitch Plate and then push the Seam Guide down to
the left.
⦁
Sliding the fabric along the right side of the guide provides
constant a cutting distance from the raw edge of the fabric.
⦁
The cutout (3) in the center of the lower mounting bar indicates
the position of the left needle. Scales are provided in mm (1)
and inches (2).
1 Scale in mm
2 Scale in inches
3 Cutout
1
2
3
When working with lowered knife, make sure that the fabric edge is not wider
than the selected cutting width. Otherwise the upper looper and the needle can
be damaged.
