BIFFI ALGAS-QA EAC User Manual

7
0.3 240 93 165 M20 4 5 17 127 70 12 75,6
0.9 310 112 254 M16 8 5 19 150 86 14 93,6
1.5 360 144 298 M20 8 6 19 190 112 18 119,0
3 430 195 356 M30 8 9 23 200 157 25 167,8
6 520 250 406 M36 8 14 29 260 200 28 212,8
Installation, Operation and Maintenance Manual
MAN616_EAC Rev. 5 July 2020
Section 2: Installation
Installation
Figure 2 Coupling Dimensions for Scotch Yoke Standard Actuators
Drive sleeve
H max
N.4 holes ange N.8 holes ange
N. THREADED HOLES
P.C.D., number and size according to ISO 5211
(but the holes are on centerline instead of
straddle the centerline)
ø d1 max
Flow line
Top view of the scotch yoke mechanism
(actuator shown in closed position)
Models from 0.3 to 6
Dimensions in millimeters
Actuator model Ø d
1
Ø d
2
Ø d
3
Ø d
4
N h
1
h
2
H max Ø d
5
W K
Table 2.
