BIFFI ALGAS-QA EAC User Manual

11
Installation, Operation and Maintenance Manual
MAN616_EAC Rev. 5 July 2020
Section 2: Installation
Installation
2.3.2 Valve Stem with Vertical Axis
NOTICE
The lifting and handling of the actuator must be done by qualied personnel and in accordance
with the laws and regulations in force. Avoid the lifted actuator to be hung above the personnel.
!
WARNING
The actuator must be lifted by means of a suitable lifting apparatus. The weight of the
actuators is indicated in the technical documentation attached to the equipment itself.
For lifting and moving the actuator, use only hooks tted with safety latch, like the one,
for example, shown in Figure 6.
Figure 6 Example of hook with safety latch
Figure 7 Lifting Points for PLAS Actuators
Lifting points: 1-2 (mandatory), 3 (balancing)
