Big Joe E30 - Page 101

BL-E30-0515 - 03-01-2018 12-31
Hydraulic System
Pos. # Part Number Description
Qty.
Reqd.
Notes
1 0000-000109-00 SCREW M8×16 2
2 1115-410000-00 LIFT CYLINDER 1
Used up to Serial #
E2017219
2a 1115-410000-0A LIFT CYLINDER 1
Used from Serial #
E2017220 to E2116209
2b 1115-410000-0B LIFT CYLINDER 1
Used from Serial #
E2116210
3 0000-000705-00 BUSHING 2
4 0000-000013-00 GREASE FITTING M8 1
5 0000-000044-00 WASHER Ø14 4
6 2401-146000-00 BOLT 1
7 2401-143500-00 BOLT 1
8 1115-420000-00 HOSE 1
9 1115-510001-00 PUMP & MOTOR ASSEMBLY 1
10 0000-000159-00 LOCKWASHER Ø8 2
