BL-E30-0515 - 03-01-2018 12-37
.Lift Cylinder Used from Serial # E2017220 to E2116209
Pos. # Part Number Description
Qty.
Reqd.
Notes
-- 1115-410000-0A LIFT CYLINDER ASSEMBLY
-- 1115-QSYG SEAL KIT FOR LIFT CYLINDER 1 Includes Pos. # 2, 3 & 7
1 1115-410001-0A PISTON ROD 1
2 0000-000672-00 RING WIPER Ø40×48×5-6.5 1
3 0000-000673-00 O-RING Ø45×3.1 1
4 1115-410002-0A CAP 1
5 1115-411000-0A CYLINDER BODY 1
6 1115-410003-00 RING BACK UP 1
7 0000-000512-00 ROD PACKING Ø40×50×6 1
To Next Page
