Big Joe E30 - Page 109

BL-E30-0515 - 03-01-2018 12-39
Lift Cylinder Used from Serial # E2116210
Pos.
#
Part Number Description
Qty.
Reqd.
Notes
-- 1115-410000-0B LIFT CYLINDER ASSEMBLY
-- 1115-QSYG SEAL KIT FOR LIFT CYLINDER 1 Includes Pos. # 2, 3 & 7
1 1115-410001-0B PISTON ROD 1
2 0000-000672-00 RING WIPER Ø40×48×5-6.5 1
3 0000-000673-00 O-RING Ø45×3.1 1
4 1115-410002-0B CAP 1
5 1115-411000-0B CYLINDER BODY 1
6 1115-410003-00 RING BACK UP 1
7 0000-000512-00 ROD PACKING Ø40×50×6 1
8 1115-410004-00 BUSHING 1
9 1115-400002-0B BLOCK 1
