Big Joe E30 - Page 111

BL-E30-0515 - 03-01-2018 12-41
Electrical System
Pos.
#
Part Number
Description
Qty.
Reqd.
Notes
1 0000-000665-00 SCREW M4×45 2
2 907200-14 CONTROLLER 1
3 1115-510005-0A HEAT SINK 1
4 0000-000121-00 SCREW M4×35 4
5 1115-500007-00 VEIL MATS 1
6 1115-511002-40 BRACKET 1
7 1115-500008-00 KEY, 3 WAY SWITCH 2
Only used on Serial #’s: E2013117,
E2013119, E2013120,E2013121,
E2013123, E2013124,E2013125,
E2013126, E2013127,E2013128,
E2013133, E2013142,E2013143,
E2014129, E2014131,E2014134,
E2014147
.
7a 1115-500010-00 KEY, 2 WAY SWITCH 2
Used up to Serial #
E2120047
7b 1115-500016-00 KEY, 2 WAY SWITCH 2
Used from serial #
E20120048
8 0000-000666-00 SCREW M3×8 2
9 1115-500006-10 CHARGER CABLE 1
10 0000-000129-00 SCREW M6×16 2
11 1120-540001-00-B FUSE STAND 1
12 1115-510003-00 FUSE 100A 1
13 1118-560006-00-01 CHARGER ASSEMBLY 1
14 0000-000031-00 SCREW M5×8 4
15 0000-000122-00 LOCKWASHER Ø4 6
16 0000-000702-00 FLATWASHER Ø4 4
17 1115-510008-00 EMERGENCY STOP SWITCH 1
Used on all trucks
except those mentioned
on Pos. # 17a.
17a 1115-510008-0A EMERGENCY STOP SWITCH 1
Only used on Serial #’s:
E2013118,E2013122,
E2013189,E2013190,
E2013191,E2013192,
E2013117,E2013119,
E2013120,E2013121,
E2013125,E2013128,
E2013126,E2013123,
E2014129,E2014131,
E2014134,E2014147,
E2013127,E2013127,
E2013143,E2013133,
E2013142
