Electrical System Continued
Pos.
#
Part Number
Description
Qty.
Reqd.
Notes
18 1115-520005-0A WIRE HARNESS 1
For BDI without hour
meter
18a 1115-520005-20 WIRE HARNESS 1
Optional: For BDI with
hour meter
19 1115-520013-00 LED WIRE HARNESS 1
20 1115-520003-00 3-WAY SWITCH ASSEMBLY 1
Only used on Serial #’s:
E2013117, E2013119,
E2013120,E2013121,
E2013123,
E2013124,E2013125,
E2013126,
E2013127,E2013128,
E2013133,
E2013142,E2013143,
E2014129,
E2014131,E2014134,
E2014147.
20a 1115-520003-0A 2-WAY SWITCH 1
Used up to Serial #
E2120047
20b 1115-520019-00 2-WAY SWITCH 1
Used from Serial #
E20120048
21 1115-520015-00 BUZZER ASSEMBLY 1
22 1115-520007-00 FAN ASSEMBLY 1
23 0000-000616-00 SCREW M5×10 2
24 0000-000194-00 FLATWASHER Ø8 2
25 0000-000196-00 NUT M8 2
26 0000-000206-00 LOCKWASHER Ø5 4
27 0000-001133-00 O-RING Ø3.15×1.8 4
28 1115-520011-00
EMERGENCY STOP SWITCH
WIRE
1
Only used on trucks
with Serial #’s men-
tioned on Pos. # 17a.
29 1115-500009-00 CHARGER HOOP 2 Used from 08/15/2012
30 1115-510009-00 LAMP HOLDER 1
31 0000-000128-00 FLATWASHER Ø5 4
32 0000-001134-00 O-RING Ø2.0×1.8 2
33 1115-510006-00 BATTERY INDICATOR 1 Without hour meter
33a 1115-510006-20 BATTERY INDICATOR 1
Optional: With hour
meter
