Big Joe E30 - Page 119

BL-E30-0515 - 03-01-2018 12-49
Wiring Cables
Pos. # Part Number Description
Qty.
Reqd.
Notes
1 1115-530008-00 BATTERY CONNECTOR CABLE 1
2 1115-530007-00 BATTERY CABLE+ 1 Used up to 06-14-2012
2a 1115-530007-10 BATTERY CABLE+ 1 Used from 06-15-2012
3--M2 CABLE 1
Not sold separately incl. in
Drive Wire Harness
4--M1 CABLE 1
Not sold separately incl. in
Drive Wire Harness
5 1115-530001-00 B CABLE + 1
6 1115-530002-00 B CABLE - 1
7 1115-530006-00 P CABLE - 1 Used up to 06-14-2012
7a 1115-530006-10 P CABLE - 1 Used from 06-15-2012
8 1115-530005-00 P CABLE + 1
9 1115-500005-00 BATTERY 2
9a 003231 BATTERY 2 Optional 12V / 85Ah
10 1115-100001-00 EPE BLOCK 2
Used up to Serial #
E2219245
10a 1115-100004-f0 EPE BLOCK 2
Used from Serial #
E2219246
11 0000-000646-00 SCREW M4×10 2
12 1115-231000-00 BRACKET 1
13 0000-000108-00 NUT M6 2 Used up to 12-12-2013
14 0000-000056-00 LOCKWASHER Ø6 2 Used up to 12-12-2013
15 0000-000380-00 FLATWASHER Ø6 2 Used up to 12-12-2013
16 0000-000004-00 SCREW M5×12 2
17 0000-000277-00 BOLT M8×25 4
18 0000-000159-00 LOCKWASHER Ø8 4
19 0000-000176-00 FLATWASHER Ø8 4
20 1115-530009-00 C3 CABLE 1
21 1115-100002-00 EPE BLOCK II 2
Used up to Serial #
E2219245
21a 1115-160000-f0 EPE BLOCK II 2
Used from Serial #
E2219246
22 1115-100003-00 EPE BLOCK III 2 Used up to 06-30-2013
22a 2112-410005-00 RUBBER CUSHION 4
Used from 07-01-2013 to
Serial # E2219245
22b 1115-100005-00 RUBBER CUSHION 2
Used from Serial #
E2219246
23 0000-000550-00 NUT M 8 2
Used from Serial #
E2219246
24 0000-000917-00 SCREW M8×45 2
Used from Serial #
E2219246
25 1115-520020-00 3M PATCH 1
Used from Serial #
E2313483
