Big Joe E30 - Page 75

BL-E30-0515 - 03-01-2018 12-5
Control Head
Pos. # Part Number Description
Qty.
Reqd.
Notes
1 SEE POS. # 24 CAP ASSEMBLY 1
2 1120-340005-00 CONTROL KNOB RIGHT SIDE 1
3 0000-000038-00 LOCKWASHER Ø3 2
4 0000-000037-00 SCREW M3×12 2
5 0000-000004-00 SCREW M5×12 2
6 0000-000206-00 LOCKWASHER Ø5 4
7 0000-000390-00 FLATWASHER Ø5 4
8 0000-000088-00 SCREW M4×8 2
9 0000-000122-00 LOCKWASHER Ø4 2
10 0000-000702-00 FLATWASHER Ø4 2
11 0000-000322-00 SCREW M8×25 2
12 0000-000159-00 LOCKWASHER Ø8 2
13 0000-000176-00 FLATWASHER Ø8 2
14 1120-340003-00 CONTROL KNOB LEFT SIDE 1
15 1120-343002-00 REVERSE BUTTON COVER 1
See Emergency
Reverse Switch
Assembly section for
details.
16 0000-000004-00 SCREW M5×12 1
17 0000-000035-00 SCREW M5×20 4
18 1120-340002-00 COVER 1
19 1120-341000-00 HANDLE 1
20 1120-340001-00 CONTROL HEAD BRACKET 1
21 1220-520008-0C ACCELERATOR ASSEMBLY 1
22 0000-000010-00 SCREW M5×6 1
23 1115-343000-00-B REVERSING SWITCH ASSEMBLY 1 With Switch
24 1120-342000-00-B CAP ASSEMBLY 1
With Wire harness.
See Emergency
Reverse Switch
Assembly section for
details.
