Transmission, Motor & Brake Assembly - Used up to serial number 426150000
Pos. # Part Number Description
Qty.
Reqd.
Notes
1 1115-200012-00 RUBBER 1 Used up to 10-24-2012
1a 1115-700002-00 GUIDE 1
Optional: Used when truck
has Speed Reduction Switch.
1b 1115-700003-00 CONNECTING PIECE 1
Optional: Used when truck
has Speed Reduction Switch.
2 1115-200011-00 BOLT M20×1.5×60 1
3 1115-200009-0A PLATE 1
4 0000-000657-00 BEARING 6010-Z 1
5 1115-200008-00 LOAD BRIDGE 1
Used up to Serial #
E2116209
5a 1115-200008-0B LOAD BRIDGE 1 Used from Serial # E2116210
6 0000-000668-00 BEARING 30212 1
7 1115-200006-0A ROUND COVER PLATE 1
8 1115-210001-0A GEAR CASE 1
9 0000-000665-00 SCREW M4×45 3
10 1115-200007-00 CAP 1
11 0000-000386-00 SCRW M6×20 8
12 0000-000056-00 LOCKWASHER Ø6 8
13 0000-000013-00 GREASE FITTING M8 1
14 0000-000704-00 PIN Ø6×20 2
15 1115-200001-00 GEAR COVER 1
16 0000-000658-00 SNAP RING FOR HOLE Ø42 1
17 0000-000659-00 SNAP RING Ø15 2
18 0000-000667-00 BEARING 61905Z 1
19 1115-GSX-10 GEAR SET 1 Includes two gears pos. # 19
20 0000-000680-00 BEARING 16003Z 1
21 1115-GSX-20 GEAR RING SET 1 Includes two gears pos. # 21
22 0000-000660-00 KEY 5×5×18 1
23 0000-000154-00 SCREW M8×35 5 Used up to 08-05-2012
23a 0000-000026-00 SCREW M8×30 5 Used from 09-05-2012
To Next Page
