Big Joe E30 - Page 83

BL-E30-0515 - 03-01-2018 12-13
Transmission, Motor & Brake Assembly - Continued - Used up to serial number 426150000
Pos. # Part Number Description
Qty.
Reqd.
Notes
24 0000-000159-00 LOCKWASHER Ø8 5
25 0000-000670-00 OIL SEAL Ø155×172×10 1
26 0000-000661-00 SCREW M5×20 6
27 0000-000206-00 LOCKWASHER Ø5 6
28 0000-000662-00 FLAT KEY 5×5×12 2
29 0000-000671-00 OIL SEAL Ø16×28×7 1
30 0000-000663-00 BEARING 61824-2RS 2
31 1115-220000-00 DRIVE WHEEL 1
32 1115-200010-00 BEARING BAFFLE 1
33 1115-230000-00 MOTOR 1
34 1115-240001-00 BRAKE LINING 1
35 1115-520012-00 BRAKE ASSEMBLY 1
36 1115-520018-00
SPEED REDUCTION SWITCH
HARNESS
1
Only used when truck
has Speed Reduction
Switch.
37 1115-700001-00 MOUNTING BASE 1
Only used when truck
has Speed Reduction
Switch.
38 0000-000701-00 SCREW M4×10 2
Only used when truck
has Speed Reduction
Switch.
39 1115-500012-00 WIRE CLAMP Y 1 Used from 10-25-2012
40 0000-001007-00 FLATWASHER Ø8 1
41 1115-230001-00 BRUSH 4
42 1115-200000-00 DRIVE ASSEMBLY 1 Includes pos. # 8-35
43 0000-000004-00 SCREW M5×12 2
44 1115-231000-00 BRACKET 1
45 1115-250003-00 BRUSH HOLDER 1
46 1115-250002-00 BRUSH SPRING 4
