BL-E30-0515 - 03-01-2018 12-19
Compartment Cover
Pos. # Part Number Description
Qty.
Reqd.
Notes
1 0000-000179-00 SCREW M6×10 4 Used up to 10-24-2012
1a 0000-000077-00 SCREW M6×12 4 Used from 10-25-2012
2 0000-000123-00 FLATWASHER Ø6 4
3 1115-120002-00 CHARGER CAP 1
4 1120-150004-00 SCREW M6×25 2
5 1115-120001-00 UPPER COVER 1 Yellow
5a 1115-120001-00-01 UPPER COVER 1 Red
5b 1115-120001-00-02 UPPER COVER 1 Orange
6 1115-120003-00 COVER 2
Used up to serial num-
ber 424191006.
Yellow - Used on Fork
Frame 27” only.
6a 1115-120003-n0 COVER 2
Used from serial num-
ber 424191007
Yellow - Used on Fork
Frame 27” only.
6b 1115-120003-00-01 COVER 2
Used up to serial num-
ber 424191006.
Red - Used on Fork
Frame 27” only.
6c 1115-120003-n0-01 COVER 2
Used from serial num-
ber 424191007
Red - Used on Fork
Frame 27” only.
6d 1115-120003-00-02 COVER 2
Used up to serial num-
ber 424191006.
Orange - Used on Fork
Frame 27” only.
6e 1115-120003-n0-02 COVER 2
Used from serial num-
ber 424191007
Orange - Used on Fork
Frame 27” only.
7 2214-150002-00 WASHER 2
8 1115-500013-00 WIRE CLAMP 1 Used from 10-25-2012
