Big Joe E30 - Page 91

BL-E30-0515 - 03-01-2018 12-21
Compartment
Pos. # Part Number Description
Qty.
Reqd.
Notes
1 0000-000989-00 SCREW M2×12 2
Used up to Serial #
E2120047
1a 0000-000981-00 SCREW M3×20 2
Used from Serial #
E2120048
2 1115-540000-00
NO LONGER AVAILABLE
BRACKET
1
Used up to Serial #
E2120047 - You have
to replace with a lot of
parts. Call Big Lift LLC.
for a list of parts.
2a 1115-500015-00 BRACKET 1
Used from Serial #
E2120048
3 0000-000179-00 SCREW M6×10 2 Used up to 02-01-2012
3a 0000-000077-00 SCREW M6×12 2 Used from 02-02-2012
4 0000-000123-00 FLATWASHER Ø6 2
5 1115-500011-00 WIRE CLAMP 1
Used from Serial #
E2120048
6 0000-000923-00 NUT M6 1
Used from Serial #
E2120048
7 1115-121001-00 COVER 1
8 0000-000494-00 SCREW M10×25 6
9 1115-121100-00 COVER 1
Used up to Serial #
E2221098
9a 1115-121100-0A COVER 1
Used from Serial #
E2221099
10 1115-520006-00 LIMIT SWITCH ASSEMBLY 1
Used up to Serial #
E2120047
10a 1115-500017-00 LIMIT SWITCH 1
Used from Serial #
E2120048
11 0000-000007-00 FLATWASHER Ø10 6
12 1115-500014-00 BRACKET 1
Used from Serial #
E2120048
13 0000-000988-00 BOLT M6×30 1
Used from Serial #
E2120048
14 0000-000063-00 LOCKWASHER Ø10 6
Used from Serial #
E2221099
