Big Joe E30 - Page 95

BL-E30-0515 - 03-01-2018 12-25
Frame
Pos. # Part Number Description
Qty.
Reqd.
Notes
1 0000-000651-00 SCREW M4×8 2
2 1115-500002-00 HARNESS CLAMP 1
3 0000-000650-00 SNAP RING FOR HOLE Ø25 2
4 0000-000016-00 SCREW M6×8 2
5 1115-400001-00 SHAFT 1
6 1115-130004-0A SHAFT 2
7 0000-000708-00 ROUND PIN Ø5×35 4
Used up to S/N
424150330
7a 0000-001456-00 ROUND PIN Ø5×35
Used from S/N
424150331
8 1115-110000-40 FORK FRAME 1
Used for 27” Wide and
48” (45”) Long Forks
8a 1115-110000-D0 FORK FRAME 1
Used for 27” Wide and
42” Long Forks
8b 1115-110000-40-01 FORK FRAME 1
Used for 27” Wide and
36” Long Forks
8c 1115-110000-30 FORK FRAME 1
Used for 22” Wide and
48” (45”) Long Forks
8d 1115-110000-d0 FORK FRAME 1
Used for 22” Wide and
42” Long Forks
8e 1115BM-110000-00 FORK FRAME 1
Used for 22” Wide and
36” Long Forks
9 1115-130002-40 LONG SHAFT 1
Used for 27” Wide
Forks
9a 1115-130002-0A LONG SHAFT 1
Used for 22” Wide
Forks
10 0000-000654-00 ROUND PIN Ø4×45 2
Used up to S/N
424150330
10a 0000-001458-00 ROUND PIN Ø4×45 2
Used from S/N
424150331
11 1115-130001-00 SHORT SHAFT 2
12 0000-000032-00 SCREW M6×25 1
Used up to Serial #
E2116209
12a 0000-000155-00 SCREW M10×40 1
Used from Serial #
E2116210
