Lift Link Assembly
Pos. # Part Number Description
Qty.
Reqd.
Notes
1 1115-131000-40 DOWN LINK 1 Used for 27” Wide Forks
1a 1115-131000-00 DOWN LINK 1 Used for 22” Wide Forks
2 0000-000294-00 SNAP RING FOR SHAFT Ø25 2
3 0000-000675-00 BUSHING 2 Used up to 02-21-2012
3a 0000-000906-00 BUSHING 2 Used from 02-22-2012
4 0000-000101-00 NUT M22×1.5 2
5 1115-132100-00 CONNECTOR 2
6 1115-132000-0B-04 LONG LINK 2 Used on 48” (45”) Forks
6a 1115-132000-0B-09 LONG LINK 2 Used on 42” Forks
6b 1115-132000-0B-02 LONG LINK 2 Used 36” Forks
7 0000-000011-00 BUSHING 4 Used up to 02-21-2012
7a 0000-000907-00 BUSHING 4 Used from 02-22-2012
8 1115-130005-4A WHEEL BRACKET 2
9 0000-000029-00 BUSHING 4 Used up to 02-21-2012
9a 0000-000908-00 BUSHING 4 Used from 02-22-2012
10 1115-130003-00 SHAFT 2
11 0000-000708-00 ROUND PIN Ø5×35 4
Used up to S/N
424150330
11a 0000-001456-00 ROUND PIN Ø5×35
Used from S/N
424150331
12 1115-130007-40 SHAFT 2
13 1115-133000-40 LOAD WHEEL 2
14 1115-132200-00-04 LONG ROD 2 Used on 48” (45”) Forks
14a 1115-132200-00-09 LONG ROD 2 Used on 42” Forks
14b 1115-132200-00-02 LONG ROD 2 Used 36” Forks
15 1115-130008-00 WASHER 4 Used from 11-29-2013
To Next Page
