FP (E1.1) 07/2017 page 6/90
Information to be observed in order to ensure optimum function of the product.
1.2.4 Word message panel structure
Type / cause of hazard.
Possible consequences.
∅ Instruction how to avoid the hazard: prohibition
Instruction how to avoid the hazard: mandatory action
Observe all other notes and information not necessarily emphasized in the same way, in order to avoid
disruptions which could result in direct or indirect injury or property damage.
1.3 Localization / position of safety labels on the chamber
The following labels are located on the chamber:
Pictograms (Warning signs)
Hot surface
• Outer chamber door
• On chamber rear next to the exhaust duct
Read operating manual
• UL chambers: outer chamber door
FP 53 FP 53-UL
Figure 1: Position of labels on the chamber front (examples)
Keep safety labels complete and legible.
Replace safety labels that are no longer legible. Contact BINDER Service.
